 Overview
The inverted Leica DMI4000 B was designed for applications in life science.
Outperforming not only the latest technical standards but also all the
ergonomic demands of a modern microscope, the automated research microscope
is also suitable for scanning cell and tissue cultures.
With its completely new fluorescence axis it guarantees ultra-brilliant
fluorescence. The internal filter wheel with motorized ExMan and FIM enables
excitation of fluorochromes in less than 20 milliseconds. The Leica DMI4000
B can be combined with any of the solutions from Leica's product range.
Key Features
- Ergonomic designed tubes with an integrated “View-Chute”
to get a glance to the sample on the stage with naked eyes
- Ergonomic designed stand in cooperation with the Fraunhofer Institute
(IAO)
- Tremendous free working range with the new S28 condenser and ultra
small stages
- Status display, all microscope settings at a glance
- Constant Colour Intensity Control (CCIC) keeps the colour temperature
in TL axis constant at 3,200k
- Integrated Interpupilary Interface for a direct access to the back
focal plane to adapt different contrasting techniques
- Fluorescence Intensity Manager (FIM) to attenuate the fluorescence
intensity
- New fluorescence filter cubes with reduced background intensity.
- No additional BG38 needed.
- Ultra fast internal filter wheel (IFW) for high-speed fluorescence
application allows to change excitation wavelengths within the range
of milliseconds
- Zero Pixel shift fluorescence facilitates overlay of images
- Motorized Excitation Manager for levelling different fluorescence
intensities in 17 reproducible steps
- Choice between round or rectangular field diaphragms to fit the eyepieces
or chip size of the camera
- Combination Contrast allows the combination of one TL contrast technique
with fluorescence (PH/FLUO or DIC/FLUO)
|
